Fabric reinforcement

Standard, Flying End and Merchant Fabric is available from stock, please see tables below.

Square Mesh Fabric
Structural Mesh Fabric
Long Mesh Fabric
Flying End 400m Mesh Fabric
Flying End Structural Mesh Fabric
Merchant Fabric
Wrapping Mesh Fabric

If you have an enquiry please complete the form by clicking here and we will be in touch shortly.

Square Mesh 4.8mtrs x 2.4mtrs (11.52sqm) - Type A

			Longitudinal Wires			Cross Wires
British Standard Reference	Size (mm)	Pitch (mm)	Area (mm²/m)	Size (mm)	Pitch (mm)	Area (mm²/m)	Kg/m²	Kg/Sheet
A393	10	200	393	10	200	393	6.16	70.96
A252	8	200	252	8	200	252	3.95	45.50
A193	7	200	193	7	200	193	3.02	34.79
A142	6	200	142	6	200	142	2.22	25.57
Standard A Type Fabric

ERL supplies reinforcing fabric (mesh) in accordance with BS 4483:1998 & BS 4483:2005, made from 98% scrap and 100% UK source materials. We supply a range of mesh including A type, B type, Flying End, Eco and a range of sizes.

We also have the capability to offer bespoke designs if required.
